Hacking Algorithms into H2O: Quantiles


By Team | minute read | November 10, 2014

Category: Uncategorized
Blog decorative banner image


This is a presentation of hacking a simple algorithm into the new dev-friendlybranch of H2O, H2O 3.0.

This is one of three “Hacking Algorithms into H2O” blogs. All three blogsstart out the same: getting the h2o-3 code and building it. They are the same until the section titled Building Our Algorithm: Copying from theExample, and then the content is customized for eachalgorithm. This blog describes computing Quantiles.

What is H2O 3.0?

As I mentioned, H2O 3.0 is a dev-friendly version of H2O, and is soon to be ouronly version. What does “dev-friendly” mean? It means:

  • No classloader: The classloader made H2O very hard to embed inother projects. No more!Witness H2O’s embedding in Spark.
  • Fully integrated into IdeaJ: You can right-click debug-as-junit any ofthe junit tests and they will Do The Right Thing in your IDE.
  • Fully gradle-ized and maven-ized: Running gradlew build will downloadall dependencies, build the project, and run the tests.

These are all external points. However, the code has undergone a majorrevision internally as well. What worked well was left alone, but whatwas… gruesome… has been rewritten. In particular, it’s now much easier towrite the “glue” wrappers around algorithms and get the full GUI, R, REST &JSON support on your new algorithm. You still have to write the math, ofcourse, but there’s not nearly so much pain on the top-level integration.

At some point, we’ll flip the previous H2Ogithub repo to have h2o-3 as our main repo, but at the moment, h2o-3 doesnot contain all the functionality in H2O, so it is in its own repo.


Building H2O 3.0

I assume you are familiar with basic Java development and how githubrepo’s work – so we’ll start with a clean github repo of h2o-3:

C:\Users\cliffc\Desktop> mkdir my-h2o
C:\Users\cliffc\Desktop> cd my-h2o
C:\Users\cliffc\Desktop\my-h2o> git clone


This will download the h2o-dev source base; took about 30secs for me from homeonto my old-school Windows 7 box. Then do an initial build:

C:\Users\cliffc\Desktop\my-h2o> cd h2o-3
C:\Users\cliffc\Desktop\my-h2o\h2o-dev> .\gradlew.bat --daemon build -x test


Note: For OSX/Linux users, use ./gradlew build --daemon build -x test instead.

:h2o-web:test UP-TO-DATE
:h2o-web:check UP-TO-DATE
Total time: 11 mins 41.138 secs


The first build took about 12mins, including all the test runs. Incrementalgradle-based builds are somewhat faster:

C:\Users\cliffc\Desktop\my-h2o\h2o-dev> .\gradlew.bat --daemon build -x test

Note: For OSX/Linux users, use ./gradlew build --daemon build -x test instead.

:h2o-web:signArchives SKIPPED
Total time: 1 mins 44.645 secs


But faster yet will be IDE-based builds. There’s also a functioning Makefilesetup for old-schoolers like me; it’s a lot faster than gradle for incrementalbuilds.

While that build is going, let’s look at what we got. There are 4 top-leveldirectories of interest here:

  • h2o-core: The core H2O system – including clustering, clouding,distributed execution, distributed Key-Value store, the web, REST and JSONinterfaces. We’ll be looking at the code and javadocs in here – there are alot of useful utilities – but not changing it.
  • h2o-algos: Where most of the algorithms lie, including GLM and DeepLearning. We’ll be copying the Example algorithm and turning it intoa quantiles algorithm.
  • h2o-web: The web interface and JavaScript. We will use jar filesfrom here in our project, but probably not need to look at the code.
  • h2o-app: A tiny sample Application which drives h2o-core and h2o-algos,including the one we hack in. We’ll add one line here to teach H2O about ournew algorithm.

Within each top-level directory, there is a fairly straightforward maven’izeddirectory structure:

src/main/java - Java source code
src/test/java - Java test code


In the Java directories, we further use water directories to hold core H2Ofunctionality and hex directories to hold algorithms and math:

src/main/java/water - Java core source code
src/main/java/hex - Java math source code


Ok, let’s setup our IDE. For me, since I’m using the default IntelliJ IDEA setup:

C:\Users\cliffc\Desktop\my-h2o\h2o-dev> gradlew idea


Note: For OSX/Linux users, use ./gradlew idea

Total time: 38.378 secs

Running H2O-dev Tests in an IDE

Then I switched to IDEAJ from my command window. I launched IDEAJ, selected“Open Project”, navigated to the h2o-3/ directory, selected the h2o-3.ipr file, and clicked Open. After IDEAJ opened, I clicked the Make project button (or Build/Make Project or ctrl-F9) and after a few seconds, IDEAJ reports the project is built (with a few dozen warnings).

Make sure to sync the “smalldata” folder as well:./gradlew syncSmalldata

Let’s use IDEAJ to run the JUnit test for the Example algorithm I mentionedabove. Navigate to the file. I used a quick double-press ofShift to bring the generic project search, then typed some and selected it from the picker. Inside the one obvioustestIris() function, right-click and select Debug testIris(). The testIris codeshould run, pass pretty quickly, and generate some output:

"C:\Program Files\Java\jdk1.7.0_67\bin\java" -agentlib:jdwp=transport=dt_socket....
Connected to the target VM, address: '', transport: 'socket'


11-08 13:17:07.536 4576 main INFO: ----- H2O started -----
11-08 13:17:07.642 4576 main INFO: Build git branch: master
11-08 13:17:07.642 4576 main INFO: Build git hash: cdfb4a0f400edc46e00c2b53332c312a96566cf0
11-08 13:17:07.643 4576 main INFO: Build git describe: RELEASE-0.1.10-7-gcdfb4a0
11-08 13:17:07.643 4576 main INFO: Build project version: 0.1.11-SNAPSHOT
11-08 13:17:07.644 4576 main INFO: Built by: 'cliffc'
11-08 13:17:07.644 4576 main INFO: Built on: '2014-11-08 13:06:53'
11-08 13:17:07.644 4576 main INFO: Java availableProcessors: 4
11-08 13:17:07.645 4576 main INFO: Java heap totalMemory: 183.5 MB
11-08 13:17:07.645 4576 main INFO: Java heap maxMemory: 2.66 GB
11-08 13:17:07.646 4576 main INFO: Java version: Java 1.7.0_67 (from Oracle Corporation)
11-08 13:17:07.646 4576 main INFO: OS version: Windows 7 6.1 (amd64)
11-08 13:17:07.646 4576 main INFO: Possible IP Address: lo (Software Loopback Interface 1),
11-08 13:17:07.647 4576 main INFO: Possible IP Address: lo (Software Loopback Interface 1), 0:0:0:0:0:0:0:1
11-08 13:17:07.647 4576 main INFO: Possible IP Address: eth3 (Realtek PCIe GBE Family Controller),
11-08 13:17:07.648 4576 main INFO: Possible IP Address: eth3 (Realtek PCIe GBE Family Controller), fe80:0:0:0:4d5c:8410:671f:dec5%11
11-08 13:17:07.648 4576 main INFO: Internal communication uses port: 54322
11-08 13:17:07.648 4576 main INFO: Listening for HTTP and REST traffic on
11-08 13:17:07.649 4576 main INFO: H2O cloud name: 'cliffc' on /, discovery address /
11-08 13:17:07.650 4576 main INFO: If you have trouble connecting, try SSH tunneling from your local machine (e.g., via port 55555):
11-08 13:17:07.650 4576 main INFO: 1. Open a terminal and run 'ssh -L 55555:localhost:54321 cliffc@'
11-08 13:17:07.650 4576 main INFO: 2. Point your browser to http://localhost:55555
11-08 13:17:07.652 4576 main INFO: Log dir: '\tmp\h2o-cliffc\h2ologs'
11-08 13:17:07.719 4576 main INFO: Cloud of size 1 formed [/]


11-08 13:17:07.722 4576 main INFO: ###########################################################
11-08 13:17:07.723 4576 main INFO: * Test class name: hex.example.ExampleTest
11-08 13:17:07.723 4576 main INFO: * Test method name: testIris
11-08 13:17:07.724 4576 main INFO: ###########################################################
Start Parse
11-08 13:17:08.198 4576 FJ-0-7 INFO: Parse result for _85a160bc2419316580eeaab88602418e (150 rows):
11-08 13:17:08.204 4576 FJ-0-7 INFO: Col type min max NAs constant numLevels
11-08 13:17:08.205 4576 FJ-0-7 INFO: sepal_len: numeric 4.30000 7.90000
11-08 13:17:08.206 4576 FJ-0-7 INFO: sepal_wid: numeric 2.00000 4.40000
11-08 13:17:08.207 4576 FJ-0-7 INFO: petal_len: numeric 1.00000 6.90000
11-08 13:17:08.208 4576 FJ-0-7 INFO: petal_wid: numeric 0.100000 2.50000
11-08 13:17:08.209 4576 FJ-0-7 INFO: class: categorical 0.00000 2.00000 3
11-08 13:17:08.212 4576 FJ-0-7 INFO: Internal FluidVec compression/distribution summary:
11-08 13:17:08.212 4576 FJ-0-7 INFO: Chunk type count fraction size rel. size
11-08 13:17:08.212 4576 FJ-0-7 INFO: C1 1 20.000 % 218 B 19.156 %
11-08 13:17:08.212 4576 FJ-0-7 INFO: C1S 4 80.000 % 920 B 80.844 %
11-08 13:17:08.212 4576 FJ-0-7 INFO: Total memory usage : 1.1 KB
Done Parse: 488


11-08 13:17:08.304 4576 FJ-0-7 INFO: Example: iter: 0
11-08 13:17:08.304 4576 FJ-0-7 INFO: Example: iter: 1
11-08 13:17:08.305 4576 FJ-0-7 INFO: Example: iter: 2
11-08 13:17:08.306 4576 FJ-0-7 INFO: Example: iter: 3
11-08 13:17:08.307 4576 FJ-0-7 INFO: Example: iter: 4
11-08 13:17:08.308 4576 FJ-0-7 INFO: Example: iter: 5
11-08 13:17:08.309 4576 FJ-0-7 INFO: Example: iter: 6
11-08 13:17:08.309 4576 FJ-0-7 INFO: Example: iter: 7
11-08 13:17:08.310 4576 FJ-0-7 INFO: Example: iter: 8
11-08 13:17:08.311 4576 FJ-0-7 INFO: Example: iter: 9
11-08 13:17:08.315 4576 main INFO: #### TEST hex.example.ExampleTest#testIris EXECUTION TIME: 00:00:00.586 (Wall: 08-Nov 13:17:08.313)


Disconnected from the target VM, address: '', transport: 'socket'
Process finished with exit code 0

Ok, that’s a pretty big pile of output – but buried it in is some cool stuff we’ll need to be able to pick out later, so let’s break it down a little.

The yellow stuff is H2O booting up acluster of 1 JVM. H2O dumps out a bunch of stuff to diagnose initial clustersetup problems, including the git build version info, memory assigned to theJVM, and the network ports found and selected for cluster communication. Thissection ends with the line:

11-08 13:17:07.719 4576 main INFO: Cloud of size 1 formed [/]


This tells us we formed a Cloud of size 1: one JVM will be running our program,and its IP address is given.

The lightblue stuff is ourExampleTest JUnit test starting up and loading some test data (the venerableiris dataset with headers, stored in the H2O-dev repo’ssmalldata/iris/ directory). The printout includes some basic stats about theloaded data (column header names, min/max values, compression ratios).Included in this output are the lines Start Parse and Done Parse. Thesecome directly from the System.out.println("Start Parse") lines we can see inthe code.

Finally, the green stuff is our Examplealgorithm running on the test data. It is a very simple algorithm (finds themax per column, and does it again and again, once per requested _max_iters).

Building Our Algorithm: Copying from the Example

Now let’s get our own algorithm framework to start playing with in place.

We want to compute Quantiles, so let’s call the code quantile_new (since quantile already exists). I cloned the main code and modelfrom the h2o-algos/src/main/java/hex/example/ directoryinto h2o-algos/src/main/java/hex/quantile/, and the test fromh2o-algos/src/test/java/hex/example/ directory intoh2o-algos/src/test/java/hex/quantile/.

Then I copied the three GUI/REST files in h2o-algos/src/main/java/hex/schemaswith Example in the name (,ExampleV3) to their Quantile* variants.

I also copied the h2o-algos/src/main/java/hex/api/ExampleBuilderHandler.javafile to its Quantile variant. Finally, I renamed the files and file contentsfrom Example to Quantile.

I also dove into h2o-app/src/main/java/hex/API/ and copied the threeExample lines and made their Quantile variants. Because I’m old-school,I did this with a combination of shell hacking and Emacs; about 5 minutes alltold.

At this point, back in IDEAJ, I nagivated to, right-clickeddebug-test testIris again – and was rewarded with my Quantile clone runninga basic test. Not a very good Quantile, but definitely a start.

Whats in All Those Files?

What’s in all those files? Mainly there is a Model and a ModelBuilder, andthen some support files.

model is a mathematical representation of the world, an effort toapproximate some interesting fact with numbers. It is a static concreteunchanging thing, completely defined by the rules (algorithm) and data usedto make it.

model-builder builds a model; it is transient and active. It exists aslong as we are actively trying to make a model, and is thrown away once wehave the model in-hand.

In our case, we want quantiles as a result – a mathematical representation ofthe world – so that belongs in the file. The algorithmto compute quantiles belongs in the file.

We also split Schemas from Models to isolate slow-moving external APIs fromrapidly-moving internal APIs. As a Java dev, you can hack the guts of Quantileto your heart’s content, including the inputs and outputs, as long as theexternally facing V2 schemas do not change. If you want to report new stuff ortake new parameters, you can make a new V3 schema (which is not compatiblewith V2) for the new stuff. Old external V2 users will not be affected byyour changes – you’ll still have to make the correct mappings in the V2 schemacode from your V3 algorithm.

One other important hack: quantiles is an unsupervised algorithm – no trainingdata (no “response”) tells it what the results “should” be. So we need to hackthe word Supervised out of all the various class names it appears in. Afterthis is done, your QuantileTest probably fails to compile, because it is tryingto set the response column name in the test, and unsupervised models do notget a response to train with. Just delete the line for now:

parms._response_column = "class";


At this point, we can run our test code again (still finding the max-per-column).

The Quantile Model

The Quantile model, in the file, should contain what weexpect out of quantiles: the quantile value – a single double. Usually peoplerequest a set of Q probabilities (e.g., the 1%, 5%, 25% and 50% probabilities),so we’ll report a double[/*Q*/] of quantiles. Also, we’ll report them forall N columns in the dataset, so it will really be a double[/*N*/][/*Q*/]. For our Qprobabilities, this will be:

public double _quantiles[/*N*/][/*Q*/]; // Our N columns, Q quantiles reported


Inside the QuantileModel class, there is a class for the model’s output:class QuantileOutput. We’ll put our quantiles there. The various supportclasses and files will make sure our model’s output appears in the correct REST &JSON responses, and gets pretty-printed in the GUI. There is also theleft-over _maxs array from the old Example code; we can delete that now.

And finally a quick report on the effort used to build the model: the numberof iterations we actually took. Our quantiles will run in iterations,improving with each iteration until we get the exact answer. I’ll describe thealgorithm in detail below, but it’s basically an aggressiveradix sort.

My final QuantileOutput class looks like:

public static class QuantileOutput extends Model.Output {
public int _iters; // Iterations executed
public double _quantiles[/*N*/][/*Q*/]; // Our N columns, Q quantiles reported
public QuantileOutput( Quantile b ) { super(b); }
@Override public ModelCategory getModelCategory() { return Model.ModelCategory.Unknown; }


Now, let’s turn to the input for our model-building process. These are storedin the class QuantileModel.QuantileParameters. We already inherit an inputtraining dataset (returned with train()), and some other helpers (e.g. whichcolumns to ignore if we do an expensive scoring step with each iteration). Fornow, we can ignore everything except the input dataset from train().

However, we want some more parameters for quantiles: the set of probabilities.Let’s also put in some default probabilities (the GUI & REST/JSON layer will letthese be overridden, but it’s nice to have some sane defaults). Define it nextto the left-over _max_iters from the old Example code (which we might as wellalso nuke):

// Set of probabilities to compute
public double _probs[/*Q*/] = new double[]{0.01,0.05,0.10,0.25,0.333,0.50,0.667,0.90,0.95,0.99};


My final QuantileParameters class looks like:

public static class QuantileParameters extends Model.Parameters {
// Set of probabilities to compute
public double _probs[/*Q*/] = new double[]{0.01,0.05,0.10,0.25,0.333,0.50,0.667,0.90,0.95,0.99};


A bit on field naming: I always use a leading underscore _ before allinternal field names – it lets me know at a glance whether I’m looking at afield name (stateful, can changed by other threads) or a function parameter(functional, private). The distinction becomes interesting when you aresorting through large piles of code. There’s no other fundamental reason touse (or not use) the underscores. External APIs, on the other hand, generally donot care for leading underscores. Our JSON output and REST URLs will strip theunderscores from these fields.

To make the GUI functional, I need to add my new probabilities field to the external schemain h2o-algos/src/main/java/hex/schemas/

public static final class QuantileParametersV2 extends ModelParametersSchema<QuantileModel.QuantileParameters, QuantileParametersV2> {
static public String[] own_fields = new String[] {"probs"};
// Input fields
@API(help="Probabilities for quantiles") public double probs[];


And I need to add my result fields to the external output schema inh2o-algos/src/main/java/hex/schemas/

public static final class QuantileModelOutputV2 extends ModelOutputSchema<QuantileModel.QuantileOutput, QuantileModelOutputV2> {
// Output fields
@API(help="Iterations executed") public int iters;
@API(help="Quantiles per column") public double quantiles[/*Q*/][/*N*/];


The Quantile Model Builder

Let’s turn to the Quantile model builder, which includes some boilerplate weinherited from the old Example code, and a place to put our real algorithm.There is a basic Quantile constructor which calls init:

public Quantile( ... ) { super("Quantile",parms); init(false); }


In this case, init(false) means “only do cheap stuff in init”. Init isdefined a little ways down and does basic (cheap) argument checking.init(false) is called every time the mouse clicks in the GUI and is used tolet the front-end sanity parameters function as people type. In this case“only do cheap stuff” really means “only do stuff you don’t mind waiting onwhile clicking in the browser”. No computing quantiles in the init() call!

Speaking of the init() call, the one we got from the old Example code limitssanity checks the now-deleted _max_iters. Let’s add some lines to check thatour _probs are sane:

for( double p : _parms._probs )
if( p < 0.0 || p > 1.0 )
error("probs","Probabilities must be between 0 and 1 ");


In the file there is a trainModel call that is used when youreally want to start running quantiles (as opposed to just checking arguments).In our case, the old boilerplate starts a QuantileDriver in a backgroundthread. Not required, but for any long-running algorithm, it is nice to have itrun in the background. We’ll get progress reports from the GUI (and fromREST/JSON) with the option to cancel the job, or inspect partial results as themodel builds.

The class QuantileDriver holds the algorithmic meat. The compute2() callwill be called by a background Fork/Join worker thread to drive all the hardwork. Again, there is some brief boilerplate we need to go over.

First up: we need to record Keys stored in H2O’s DKV: DistributedKey/Value store, so a later cleanup, Scope.exit();, will wipe out any tempkeys. When working with Big Data, we have to be careful to clean up afterourselves – or we can swamp memory with Big Temps.



Next, we need to prevent the input datasets from being manipulated by otherthreads during the model-build process:



Locking prevents situations like accidentally deleting or loading a new datasetwith the same name while quantiles is running. Like the Scope.exit() above,we will unlock in the finally block. While it might be nice to use Java locking,or even JDK 5.0 locks, we need a distributed lock, which is not provided byJDK 5.0. Note that H2O locks are strictly cooperative – we cannotenforce locking at the JVM level like the JVM does.

Next, we make an instance of our model object (with no clusters yet) and placeit in the DKV, locked (e.g., to prevent another user from overwriting ourmodel-in-progress with an unrelated model).

model = new QuantileModel(dest(), _parms, new QuantileModel.QuantileOutput(Quantile.this));


Also, near the file bottom is a leftover class Max from the old Example code.Might as well nuke it now.

The Quantile Main Algorithm

Finally we get to where the Math is!

Quantiles can be computed in a variety of ways, but the most common startingpoint is to sort the elements – then, finding the Nth element is easy. Alas,sorting large datasets is expensive. Also, sorting provides a total order onthe data, which is overkill for what we need. Instead, we’ll do a couple ofrounds of a radix-sort, refining our solution with each iteration until we getthe exact answer. The key metric in a radix sort is the number of bins used;we want all our bins to fit in cache, probably even L1 cache, so we’ll startwith limiting ourselves to 1024 bins.

Given a histogram / radix-sort of 1024 bins on a billion rows, each bin willrepresent approximately 1 million rows. We then pick the bin holding the Nthelement, and re-bin / re-histogram / re-radix-sort another 1024 bins refiningthe bin holding the Nth element. We expect this bin to hold about 1000elements. Finding the Nth element in a billion rows then probably takes 3 or 4passes (worst case is sorta bad: 100 passes), and each pass will be really fast.

Basically, we’re gonna fake a sort – we’ll end up with the elements for theexact row numbers we want for each probability (and not all the other rownumbers). E.g., if the probability of 0.4567 on a billion row dataset needsthe element (in sorted order) for row 456,700,000 – we’ll get it (this elementis not related to the unsorted row number 456,700,000).

Besides a classic histogram (element counts per bucket), we will also need anactual value – if there is a unique one. This is always true if we only have oneelement in a bucket, but it might also be true if we have a long run of thesame value (e.g., lots of the year 2014’s in our dataset).

My Quantile now has a leftover loop from the old Example code running up tosome max iteration count. Let’s nuke it and just run a loop over all thedataset columns.

// Run the main Quantile Loop
Vec vecs[] = train().vecs();
for( int n=0; n<vecs.length; n++ ) {


Let’s also stop if somebody clicks the “cancel” button in the GUI:

for( int n=0; n<vecs.length; n++ ) {
if( !isRunning() ) return; // Stopped/cancelled


I removed the “compute Max” code from the old Example code in the loop body.Next up, I see code to record any new model (e.g. quantiles), and savethe results back into the DKV, bump the progress bar, and log a little bit ofprogress:

// Update the model
model._output._quantiles = ????? // we need to figure these out
model._output._iters++; // One iter per-prob-per-column
model.update(_key); // Update model in K/V store
update(1); // One unit of work in the GUI progress bar
StringBuilder sb = new StringBuilder();
sb.append("Quantile: iter: ").append(model._output._iters);;

The Quantile Main Loop

And now we need to figure what do in our main loop. Somewhere between theloop-top-isRunning check and the model.update() call, we need to computesomething to update our model with! This is the meat of Quantile – for eachpoint, bin it – build a histogram. With the histogram in hand, we see if wecan compute the exact quantile, if we cannot and then build a new refinedhistogram from the bounds computed in the prior histogram.

Anything that starts out with the words “for each point” when you have a billionpoints needs to run in-parallel and scale-out to have a chance of completingfast – and this is exactly H2O is built for! So let’s write code that runsscale-out for-each-point… and the easiest way to do that is with an H2OMap/Reduce job – an instance of MRTask. For Quantile, this is an instance ofa histogram. We’ll call it from the main-loop like this, anddefine it below (extra lines included so you can see how it fits):

if( !isRunning() ) return; // Stopped/cancelled
Vec vec = vecs[n];
// Compute top-level histogram
Histo h1 = new Histo(/*bounds for the full Vec*/).doAll(vec); // Need to figure this out???
// For each probability, see if we have it exactly - or else run
// passes until we do.
for( int p = 0; p < _parms._probs.length; p++ ) {
double prob = _parms._probs[p];
Histo h = h1; // Start from the first global histogram
while( h.not_have_exact_quantile??? ) // Need to figure this out???
h = h.refine_histogram???? // Need to figure this out???
// Update the model
model._output._iters++; // One iter per-prob-per-column
model.update(_key); // Update model in K/V store
update(1); // One unit of work
StringBuilder sb = new StringBuilder();
sb.append("Quantile: iter: ").append(model._output._iters).append(" Qs=").append(Arrays.toString(model._output._quantiles[n]));;


Basically, we just called some not-yet-defined Histo code on the entire Vec(column) of data, then looped over each probability. If we can compute thequantile exactly for the probability, great! If not, we build and run anotherhistogram over a refined range, repeating until we can compute the exacthistogram. I also printed out the quantiles per Vec, so we can watch theprogress over time. Now class Histo can be coded as an inner class to theQuantileDriver class:

class Histo extends MRTask<Histo> {
private static final int NBINS=1024; // Default bin count
private final int _nbins; // Actual bin count
private final double _lb; // Lower bound of bin[0]
private final double _step; // Step-size per-bin
private final long _start_row; // Starting row number for this lower-bound
private final long _nrows; // Total datasets rows
// Big Data output result
long _bins [/*nbins*/]; // Rows in each bin
double _elems[/*nbins*/]; // Unique element, or NaN if not unique
private Histo( double lb, double ub, long start_row, long nrows ) {
_nbins = NBINS;
_lb = lb;
_step = (ub-lb)/_nbins;
_start_row = start_row;
_nrows = nrows;
@Override public void map( Chunk chk ) {
@Override public void reduce( Histo h ) {


A Quick H2O Map/Reduce Diversion

This isn’t your Hadoop-Daddy’s Map/Reduce. This is an in-memory super-fastmap-reduce… where “super-fast” generally means “memory bandwidth limited”,often 1000x faster than the usual hadoop-variant – MRTasks can often touch agigabyte of data in a millisecond, or a terabyte in a second (depending on how muchhardware is in your cluster – more hardware is faster for the same amount ofdata!)

The map() call takes data in Chunks – where each Chunk is basically asmall array-like slice of the Big Data. Data in Chunks is accessed with basicat0 and set0 calls (vs accessing data in Vecs with at and set). Theoutput of a map() is stored in the Histo object itself, as a Plain OldJava Object (POJO). Each map() call has private access to its own fields andChunks, which implies there are lots of instances of Histo objectsscattered all over the cluster (one such instance per Chunk of data…well, actually one instance per call to map(), but each map call is handed analigned set of Chunks, one per feature or column in the dataset).

Since there are lots of little Histos running about, their results need to becombined. That’s what reduce does – combine two Histos into one.Typically, you can do this by adding similar fields together – often arrayelements are added side-by-side, similar to a saxpy operation.

This also means that any objects created or initialized in the constructor iscopied about and shared – generally read-only – in all the little Histos thatare running about. Objects made in the map() calls are private to thatinstance – and lots are getting made and must be reduced. Hence we do notset _bins and _elems in the constructor – these are our results – they willbe created new and empty in the map call instead.

All code here is written in a single-threaded style, even as it runs inparallel and distributed. H2O handles all the synchronizationissues.


Back to class Histo, we create arrays to hold our results and loop over thedata:

@Override public void map( Chunk[] chks ) {
long bins [] = _bins =new long [_nbins];
double elems[] = _elems=new double[_nbins];
for( int row=0; row<chk._len; row++ ) {
double d = chk.at0(row);


Then we need to find the correct bin (simple linear interpolation). If the binis in-range, increment the bin count. Note that if a value is missing, itwill represented as a NaN, then the computation of idx will be a NaN and therange test will fail and no bin will be incremented.

for( int row=0; row<chk._len; row++ ) {
double d = chk.at0(row);
double idx = (d-_lb)/_step;
if( !(0.0 <= idx && idx < bins.length) ) continue;
int i = (int)idx;


Also gather a unique element in the bin, if there is a unique element (otherwise, use NaN).

int i = (int)idx;
if( bins[i]==0 ) elems[i] = d; // Capture unique value
else if( !Double.isNaN(elems[i]) && elems[i]!=d )
elems[i] = Double.NaN; // Not unique
bins[i]++; // Bump row counts


And that ends the map call and the Histo main work loop. To recap, here itis all at once:

@Override public void map( Chunk chk ) {
long bins [] = _bins =new long [_nbins];
double elems[] = _elems=new double[_nbins];
for( int row=0; row<chk._len; row++ ) {
double d = chk.at0(row);
double idx = (d-_lb)/_step;
if( !(0.0 <= idx && idx < bins.length) ) continue;
int i = (int)idx;
if( bins[i]==0 ) elems[i] = d; // Capture unique value
else if( !Double.isNaN(elems[i]) && elems[i]!=d )
elems[i] = Double.NaN; // Not unique
bins[i]++; // Bump row counts


The reduce needs to fold together the returned results; the _elems and the_bins. It’s a bit tricky for the unique elements – either the left Histo orthe right Histo might have zero, one, or many elements – and if they both have aunique element, it might not be the same unique element.

@Override public void reduce( Histo h ) {
for( int i=0; i<_nbins; i++ ) // Keep unique elements
if( _bins[i]== 0 ) _elems[i] = h._elems[i]; // Left had none, so keep right unique
else if( h._bins[i] > 0 && _elems[i] != h._elems[i] )
_elems[i] = Double.NaN; // Left & right both had elements, but not equal


And that completes the Big Data portion of Quantile.

From Histogram to Quantile

Now we get to the nit-picky part of Quantiles. This isn’t Big Data, but it isMath. Gotta get it right! We have this code we need to figure out:

while( h.not_have_exact_quantile??? ) // Need to figure this out???
h = h.refine_histogram???? // Need to figure this out???


Let’s make a function to return the exact Quantile (if we can compute it, or useNaN otherwise). We’ll call it like this, capturing the quantile in the modeloutput as we test for NaN:

while( Double.isNaN(model._output._quantiles[n][p] = h.findQuantile(prob)) )
h = h.refine_histogram???? // Need to figure this out???


For the findQuantile function we will:- Find the fractional (sorted) row number for the given probability.- Find the lower actual integral row number. If the probability evenly divides the dataset, then we want the element for the sorted row. If not, we need both elements on either side of the fractional row number.- Find the histogram bin for the lower row.- Find the unique element for this bin, or return a NaN (need another refinement pass)- Repeat for the higher row number: find the bin, find the unique element or return NaN.- With the two values spanning the desired probability in-hand, compute the quantile. We’ll use R’s Type-7 linear interpolation, but we could just as well use any of the other types.

Here’s my findQuantile code:

double findQuantile( double prob ) {
double p2 = prob*(_nrows-1); // Desired fractional row number for this probability
long r2 = (long)p2; // Lower integral row number
int loidx = findBin(r2); // Find bin holding low value
double lo = (loidx == _nbins) ? binEdge(_nbins) : _elems[loidx];
if( Double.isNaN(lo) ) return Double.NaN; // Needs another pass to refine lo
if( r2==p2 ) return lo; // Exact row number? Then quantile is exact
long r3 = r2+1; // Upper integral row number
int hiidx = findBin(r3); // Find bin holding high value
double hi = (hiidx == _nbins) ? binEdge(_nbins) : _elems[hiidx];
if( Double.isNaN(hi) ) return Double.NaN; // Needs another pass to refine hi
return computeQuantile(lo,hi,r2,_nrows,prob);


And a couple of simple helper functions:

private double binEdge( int idx ) { return _lb+_step*idx; }
// bin for row; can be _nbins if just off the end (normally expect 0 to nbins-1)
private int findBin( long row ) {
long sum = _start_row;
for( int i=0; i<_nbins; i++ )
if( row < (sum += _bins[i]) )
return i;
return _nbins;


Finally the computeQuantiles call:

static double computeQuantile( double lo, double hi, long row, long nrows, double prob ) {
if( lo==hi ) return lo; // Equal; pick either
// Unequal, linear interpolation
double plo = (double)(row+0)/(nrows-1); // Note that row numbers are inclusive on the end point, means we need a -1
double phi = (double)(row+1)/(nrows-1); // Passed in the row number for the low value, high is the next row, so +1
assert plo <= prob && prob < phi;
return lo + (hi-lo)*(prob-plo)/(phi-plo); // Classic linear interpolation


Refining a Histogram

Now we need to define how to refine a Histogram. Let’s just admit it needs aBig Data pass up front and call the doAll() in the driver loop directly:

while( Double.isNaN(model._output._quantiles[n][p] = h.findQuantile(prob)) )
h = h.refinePass(prob).doAll(vec); // Full pass at higher resolution


Then the refinePass call needs to make a new Histogram from the old one, withrefined endpoints. The original Histogram had endpoints of vec.min() andvec.max(), but here we’ll use endpoints from the same bins thatfindQuantiles uses.

Histo refinePass( double prob ) {
double prow = prob*(_nrows-1); // Desired fractional row number for this probability
long lorow = (long)prow; // Lower integral row number
int loidx = findBin(lorow); // Find bin holding low value
// If loidx is the last bin, then high must be also the last bin - and we
// have an exact quantile (equal to the high bin) and we didn't need
// another refinement pass
assert loidx < _nbins;
double lo = binEdge(loidx); // Lower end of range to explore
// If probability does not hit an exact row, we need the elements on
// either side - so the next row up from the low row
long hirow = lorow==prow ? lorow : lorow+1;
int hiidx = findBin(hirow); // Find bin holding high value
// Upper end of range to explore - except at the very high end cap
double hi = hiidx==_nbins ? binEdge(_nbins) : binEdge(hiidx+1);
long sum = _start_row; // Compute adjusted starting row for this histogram
for( int i=0; i<loidx; i++ )
sum += _bins[i];
return new Histo(lo,hi,sum,_nrows);

Running Quantile

Running the QuantileTest returns:

11-13 12:19:04.179 1940 FJ-0-7 INFO: Quantile: iter: 11 Qs=[4.4, 4.6000000000000005, 4.800000000000001, 5.1000000000000005, 5.4, 5.800000000000001, 6.300000000000001, 6.4, 6.9, 7.255000000000001, 7.7]
11-13 12:19:04.183 1940 FJ-0-7 INFO: Quantile: iter: 22 Qs=[2.2, 2.345, 2.5, 2.8000000000000003, 2.9000000000000004, 3.0, 3.2, 3.3000000000000003, 3.61, 3.8000000000000003, 4.151]
11-13 12:19:04.187 1940 FJ-0-7 INFO: Quantile: iter: 33 Qs=[1.1490000000000002, 1.3, 1.4000000000000001, 1.6, 2.5787, 4.35, 4.9, 5.1000000000000005, 5.800000000000001, 6.1000000000000005, 6.7]
11-13 12:19:04.191 1940 FJ-0-7 INFO: Quantile: iter: 44 Qs=[0.1, 0.2, 0.2, 0.30000000000000004, 0.8468, 1.3, 1.6, 1.8, 2.2, 2.3000000000000003, 2.5]
11-13 12:19:04.194 1940 FJ-0-7 INFO: Quantile: iter: 55 Qs=[0.0, 0.0, 0.0, 0.0, 0.6169999999999999, 1.0, 1.383, 2.0, 2.0, 2.0, 2.0]


You can see the Quantiles-per-column (and there are 11 of them by default, sothe iteration printout bumps by 11’s). I checked these numbers vs R’sdefault Type 7 quantiles for the iris dataset and got the same numbers.

Iris is too small to trigger the refinement pass, so I also tested – an oldforest covertype dataset with about a half-million rows. Took about 0.7seconds on my laptop to compute 11 quantiles exactly, on 55 columns and 581000rows.

Good luck with your own H2O algorithm,

 headshot Team

At, democratizing AI isn’t just an idea. It’s a movement. And that means that it requires action. We started out as a group of like minded individuals in the open source community, collectively driven by the idea that there should be freedom around the creation and use of AI.

Today we have evolved into a global company built by people from a variety of different backgrounds and skill sets, all driven to be part of something greater than ourselves. Our partnerships now extend beyond the open-source community to include business customers, academia, and non-profit organizations.
